| 원래 장소: | 중국 |
| 브랜드 이름: | XZH TEST |
| 인증: | CE/ISO |
| 모델 번호: | XHGX507 |
| Identification Method | Flexible caliper intelligent identification |
| Cable Capacity | 1 to 20 cables can be calibrated |
| Calibration Range | 75% to 135% of calibration value |
| Direction Requirement | Transmitting clamp, receiving clamp and loading signal must be in same direction |
| Detection Range (Direct) | 0Ω~8kΩ loop resistance (0-20km cable length) |
| Detection Range (Coupling) | 0Ω~1kΩ loop resistance (0-6cm cable length) |
| Display | 4.3-inch LCD color screen (high brightness) |
| Touch Interface | Capacitive touch |
| Dimensions | 350mm × 155mm × 700mm (L×W×H) |
| Weight | Approximately 2kg |
| Connections | Type-C USB port, aviation socket |
| Coil Inner Diameter | φ200mm (custom sizes available) |
| Operating Conditions | -10ºC to 40ºC; ≤80% RH |
| Storage Conditions | -10ºC to 50ºC; ≤95% RH (no condensation) |
| Safety Standards | IEC61010-1 CAT III 600V, IEC61010-031, IEC61326, pollution degree 2 |
